What Is That Thing?

Recently I purchased a Dremel® power tool and noticed a black plastic device mounted on the power cord. On this device the words “Do Not Remove” were prominently displayed.  This piqued my curiosity, so I search the web for the “Emtag” and “Do Not Remove” and found numerous results.  Most of which gave confusing information about this device.  Some said it was to suppress high frequency interference in electronic circuits.  Some said it was a tracking device.

Emtag picture
Emtag Side A
Emtag Side B
Emtag Side B
Emtag removed pic
Emtag Removed

Not being able to live with this information void, I decided to try a test, contrary to all warnings and remove the device!  I just used pliers to squeeze the device until it separated into two pieces.

The Dremel still ran!  But was I now interfering with my wireless network while grinding, shaping and polishing?  Looking at the inside of the removed Emtag™, I saw something familiar.  This flat white plastic tag (seen in the picture Emtag Removed) is commonly used in stores to prevent theft.

Emtag™ is a anti-shoplifting device that is attached to electrical product cords using electronic article surveillance (EAS) to prevent theft. The Emtag™ device is manufactured by B&G International Inc. and contains a Sensormatic Supertag acousto-magnetic (AM) tag. These AM devices are typically attached to products and packaging during manufacturing. The devices are sensed by special antennas located at exits from a store or building. The Emtag™ comes in several sizes for attachment to power codes of different sizes.

This device can safely be removed (after purchase) from power tools without affecting the performance of the tool.  This device has nothing to do with suppressing high frequency noise in electronic circuits like ferrite rings.  In fact, it is similar to those mattress tags that say “Do Not Remove” in that they are unneeded after you get your purchase home.

D-Link Router Backdoor Vulnerability

The US-CERT, a part of the Department of Homeland Security,  has issued a warning that certain D-Link routers have firmware that contains a backdoor for remote users to access router administrative functions without entering the administrator password.  Besides D-Link, Planex and Alpha Networks devices may also contain this firmware.

According to D-Link, the following D-Link routers are affected:

  • DIR-100
  • DIR-120
  • DI-624S
  • DI-524UP
  • DI-604S
  • DI-604UP
  • DI-604+
  • TM-G5240

For more detailed up-to-date information go to this D-Link page on this issue.

According to the original vulnerability report, the following Planex routers are likely affected:

  • BRL-04R
  • BRL-04UR
  • BRL-04CW

If you have one of these routers, check to make sure that the remote configuration from the Internet is not allowed (default setting).  This may have been changed by ISPs that remotely administer customers Internet connections.

Security researcher Craig Heffner found these routers’ internal web server will accept and process any HTTP requests that contain the User-Agent string “xmlset_roodkcableoj28840ybtide” without checking if the connecting host is authenticated.

DNSChanger malware

If you use default passwords on your home or office gateway/router, then you maybe at risk from the DNSChanger malware.  This can affect how your computers translate domain names such as apple.com, microsoft.com and other domain names to the unique Internet Protocol (IP) address such as 198.51.100.1 that we ultimately depend on to access other computers.  A company in Estonia called Rove Digital has been operating since 2007 and may have affected more that 500,000 computers in the United States alone.  If your computer is affected, it will fail to access the Internet after July 9, 2012.

The Domain Name System (DNS) is a critical Internet service that converts user-friendly domain names, such as www.fbi.gov, into numerical addresses that allow computers to talk to each other. Without DNS and the DNS servers operated by Internet service providers, computer users would not be able to browse websites or send e-mail.

DNSChanger malware causes a computer to use rogue DNS servers in one of two ways.

  1. The malware changes the computer’s DNS server settings to replace the ISP’s good DNS servers with rogue DNS servers operated by the criminal.
  2. The malware attempts to access devices on the victim’s small office/home office (SOHO) network that run a dynamic host configuration protocol (DHCP) server (eg. a router or home gateway). The malware attempts to access these devices using common default usernames and passwords and, if successful, changes the DNS servers these devices use from the ISP’s good DNS servers to rogue DNS servers operated by the criminals. This is a change that may impact all computers on the SOHO network, even if those computers are not infected with the malware.

To assist victims affected by the DNSChanger malicious software, the FBI obtained a court order authorizing the Internet Systems Consortium (ISC) to deploy and maintain temporary clean DNS servers. This solution is temporary, providing additional time for victims to clean affected computers and restore their normal DNS settings. The clean DNS servers will be turned off on July 9, 2012, and computers still impacted by DNSChanger may lose Internet connectivity at that time.

The following table list sites setup to help you determine if your computer is affected.

URL

Language

Maintainer

http://www.dns-ok.us/ English DNS Changer Working Group (DCWG)
http://www.dns-ok.de/ German Bundeskriminalamt (BKA)
Bundesamt für Sicherheit in der Informationstechnik (BSI)
http://www.dns-ok.fi/ Finish CERT-Fi
http://www.dns-ok.ax/ Swedish CERT-Fi
http://www.dns-ok.be/ Dutch/French CERT.be
http://www.dns-ok.fr/ French CERT-LEXSI
http://www.dns-ok.ca/ English/French CIRA and CCIRC
http://www.dns-ok.lu/ English CIRCL
http://dns-ok.nl/ Dutch/English SIDN

For more technically oriented people the following is a list of IP address the criminals used for their activities.

List of Rogue DNS Server Addresses

  • 85.255.112.0 through 85.255.127.255
  • 67.210.0.0 through 67.210.15.255
  • 93.188.160.0 through 93.188.167.255
  • 77.67.83.0 through 77.67.83.255
  • 213.109.64.0 through 213.109.79.255
  • 64.28.176.0 through 64.28.191.255

For more information see the following links:

http://www.fbi.gov/news/stories/2011/november/malware_110911/malware_110911

DNS Changer Working Group (DCWG)

http://www.fbi.gov/newyork/press-releases/2011/manhattan-u.s.-attorney-charges-seven-individuals-for-engineering-sophisticated-internet-fraud-scheme-that-infected-millions-of-computers-worldwide-and-manipulated-internet-advertising-business

Update 2015-01-02: Many sites linked from this page are no longer available.

Uncle Sam Needs You!

We need your help prevent United States Senate Bill 968 (PIPA) and HR 3261 (SOPA) from becoming U.S. law. These bills are essentially a technical solution (a flawed one) for a business problem.  These laws would short-circuit due process of existing laws and provide a sledge hammer for businesses to take down their competitors.  These laws are the wrong solution for the described problem.  A group of Internet inventors and engineers have voiced their opinion in an open letter to Congress stating their opposition to the SOPA and PIPA bills.  Ironically some provisions in these bills would attack Free Speech in ways we condemn in China and Iran.

Uncle Sam needs youWe need you to help over come the well funded lobbying effort to create these laws!  Some opponents of PIPA and SOPA: Google, Yahoo, Wikipedia, craigslist, Facebook, Twitter, LinkedIn, eBay, AOL, Mozilla, Reddit, Tumblr, Etsy, Zynga, EFF, ACLU, Human Rights Watch, Darrell Issa (R-CA), Ron Wyden (D-OR), Nancy Pelosi (D-CA), Ron Paul (R-TX), Tim O’Reilly.

To find out how you representative is voting go to SOPA Opera to find out.  Then contact them and tell them how you feel about keeping the Internet a fair and open place to socialize and work.

Here are some of the people and companies that are working against your interests and for their own profit: RIAA, MPAA, News Corp, Time Warner, Walmart, Nike, Tiffany, Chanel, Rolex, Sony, Juicy Couture, Ralph Lauren, VISA, Mastercard, Comcast, ABC, Dow Chemical, Monster Cable, Teamsters, Rupert Murdoch, Lamar Smith (R-TX), John Conyers (D-MI), Michael F. Bennet (D-CO).

Simple Intrusion Detection

Sometimes I want to have a simple way to determine if a file has been changed or has been compromised without the configuration required of a full feature IDS such as AIDE or Tripwire.  This technique uses CFV, a free and open-source program written in Python and “has been verified to work on linux, freebsd, openbsd, netbsd, solaris, macosx, and windows.”  This program can generate a variety of checksum formats including the SHA1 used in this example.

To create the signature file for a directory’s and sub-directories’ files use the following commands in a Linux or Mac OS X command window:

cd /usr/local/bin
cfv -C -rr -f bin.sha1 -t sha1
gpg -sab bin.sha1

To verify the file signatures use the following commands:

cd /usr/local/bin
gpg --verify bin.sha1.asc
cfv -M -f bin.sha1

The gpg command verifies the integrity of the signature file (bin.sha1).  The cfv command then verifies all the files originally tested when creating the signature file.

Amazon Simple Storage Service (S3)

I have been using Amazon Simple Storage Service (S3) for several years to provide off-site backup and synchronizing files on my numerous systems.  It is a cloud-based service that provides storage for a very reasonable cost ($0.14 per GB/Month as of 7/19/2011).  Access to files on S3 are through web service interfaces (REST, SOAP, and BitTorrent) that are not for general use.  So most access is through some end-user program or service.  Many services have been built that use S3 including Netflix, Tumblr, reddit, and SmugMug with the list growing rapidly.

To use this service, I use a variety of tools including command-line utility called s3cmd, on my Linux systems to synchronize directories and upload/download files.  Synchronizing a directory is as simple as:

s3cmd sync /home/dirk/data s3://bta-bucket/dirk/

This will create a “directory” data in the S3 “directory” bta-bucket/dirk; upload the files that have changed or do not exist on S3 and store file metadata date/time information to make all this possible.  The only problem I have run into is s3cmd’s get and put commands do not use this file metadata to set the file modification time.  This prevents using get and put where you have used the sync command, because the file modification time will not be saved (in S3 headers) or set (on local PC) with get and put.  So to restore one file to a directory AND set the file modification time set during the sync upload use the following command:

s3cmd sync s3://bta-bucket/dirk/data/somefile.ods /home/dirk/data/somefile.ods

The local file date should match the original file’s modification date/time.  Note: the date/time shown by the s3cmd ls command is the upload date/time, NOT the file modification date/time.  The file metadata is stored in the S3 metadata headers with the Key  = “x-amz-meta-s3cmd-attrs” with a Value similar to: “uid:1000/gname:dirk/uname:dirk/gid:1000/mode:33188/mtime:1302623148/atime:1311007748/ctime:1302627027” to hold the file information.

Other S3 utilities save file metadata in different and incompatible ways, so be careful in choosing your S3 backup software and remember that changing to another utility may cause problems with synchronization based on the file modification date/time.

For Windows users, there is a free client called DragonDisk that uses S3 for file storage.  I have not used it, so this is not a recommendation.

MySQL and UTF-8

I recently had a problem in a web application that I created where the UTF-8 characters were not interpreted correctly by browsers.  The biggest issue was this did not happen in all instances of presenting these UTF-8 strings.

After tracing the strings through several libraries, I found the culprit.  The following SQL statement was the source of the text.

SELECT ID, CONCAT(sDescription, ' (', ID, ')') FROM ProdFamily;

Where ID is a integer key for the table and sDescription is a varchar column.  The result of the CONCAT function is a “binary string” because of the integer column as one of the operands.  The end result is that this “binary string” was treated differently than a regular UTF-8 string and characters outside the normal ASCII ones were not display correctly.  To fix this issue the CAST function must be added to set the type of the ID column to string as follows.

SELECT ID, CONCAT(sDescription, ' (', CAST(ID AS CHAR), ')') FROM ProdFamily

See MySQL CONCAT or CAST function documentation for more information.

MySQL: Setting date field default to current date

In MySQL, creating a date/time stamp field that defaults to the current date/time has been a problem in the past.  MySQL restricted you to one timestamp field per table that is automatically updated with the current date/time.  Early versions of MySQL allowed multiple updating timestamp fields contrary to the specification, but this was “fixed” in later versions.  Then triggers were added to MySQL v5.0.2 and can be used as a solution for this common issue.

CREATE TRIGGER `TableName_dtColumn_default` BEFORE INSERT ON `TableName`  FOR EACH ROW SET NEW.dtColumn = CURRENT_TIMESTAMP;

Replace “TableName” with your table’s name and “dtColumn” with your date/time column’s name.  Also the trigger name, “TableName_dtColumn_default” in this example, must be unique within a schema.

MySQL triggers are a very versatile feature.  For more details about creating and using triggers see the MySQL documentation for CREATE TRIGGER syntax.

Internet Everywhere

If you do business using the Internet, there are fewer and fewer places that you cannot get an Internet connection.  As an experiment I took my laptop on my lastest vacation (really geeky, I know) to see how good Internet connections were from Cozumel and Akumal, Mexico.  In both the condos I stayed in provided Internet connections (DSL in these cases) with wireless access.  The connections were good and never went down while I was using them, mostly to upload my vacation pictures.

I am currently writing this post on my Delta flight from 36,000 feet, flying at 500 mph over Missouri using a service called GoGo Inflight Internet.  The service is a little pricey at $12.95 per flight, but other options are available and would be worth it if you fly alot and need to use the Internet.

Also Internet access was available for free at many restaurants that I frequented on my vacation, usually requiring a pass code, but in most cases free.  Denver International Airport (DIA, DEN) has provided free wireless Internet access for several years.  I was kind of surprised while waiting for a connection in Atlanta that they do not provide free Internet access.  The Atlanta airport does have several wireless access services available that will charge your credit card for 24 hours of access, but I only needed it for an hour or two between flights.  If the Turtle Bakery in Akumal, Mexico can provide free wireless Internet, why can’t Atlanta.  Come on Atlanta, try to keep up with Denver and Akumal!

So, from 38,000 feet over Grand Island, Nebraska, adiós for now.

AC Adapter Hell!

Box of AC adapters
I have several boxes of orphaned AC adapters, at least I think they are orphaned.  Many of the AC adapters that come with computer or electronic accessories are not marked with any identifying marks that indicate to what product they belong.  Most manufacturers purchase AC adapters for their products off-the-shelf, so even the manufacturers name of the adapter does not help identify the device with which it belongs.

I have tried several solutions to this device/adapter linking problem. First, I tried putting labels on the adapters and writing the device on the label. Just a month or two later the label would come off, mostly due to the heat of the adapter.

Picture of AC adapter transformer block with lable
Well my most recent solution seems to work pretty well.  I found an Artline Paint Marker in white that I use to write the device on the AC adapter transformer block.  These markers are similar to a Sharpie marking pen, except they contain paint instead of ink and come in light opaque colors that contrast nicely with mostly black AC adapter transformer blocks.

Another benefit to this labeling, is when unplugging a device from a power strip, I do not have to guess or trace wire through a rat’s nest of wires to find the correct AC adapter to unplug.

I still have a box of orphaned AC adapters from devices that are obsolete or broken. At least now I have a chance to pair it up with a new device without hours of research.
